Specification
Value
Impact Energy Class
2000 ft·lbf
Blows per Minute
450-1000
Minimum Operating Weight
2095 lb
Maximum Operating Weight
2381 lb
Minimum Rated Flow
16 gal/min
Maximum Rated Flow
32 gal/min
Minimum Operating Pressure
2176 psi
Maximum Operating Pressure
2321 psi
Tool Shaft Diameter
3.92 in
Minimum Carrier Weight
24300 lb
Maximum Carrier Weight
39700 lb
<ul><li>Hammer hits with consistent power, delivering constant production.</li><li>Operation cycle is more efficient – less waste in internal heat, more power delivered to the tool.</li><li>Piston and tool are matched in diameter and mass, greatly increasing efficiency in power transmission.</li><li>Blow frequency, hydraulic pressure and impact energy have been tuned to produce the highest possible work rates on Cat machines.</li></ul>
<li>No need for constant checking of the gas charge.</li> Design keeps gas pressure steady through the duration of the annual service interval.</li>
<li>All daily checks and routine service can be performed with the hammer attached to the machine.</li><li>Spend more time working and less time on service.</li> Greasing can be performed quickly from one standing-height grease point.</li><li>Service the lower bushing in the field using simple hand tools.</li>
<li>Lower bushing is rotatable – more service life lower parts cost.</li>
<li>Optional on-board autolube provides continual greasing as the hammer runs, protecting your investment.</li><li>Available for extreme environments, the optional wear package protects the hammer housing from damage.</li></ul>
<li>All daily checks and routine service can be performed with the hammer attached to the machine.</li><li>Spend more time working and less time on service.</li> Greasing can be performed quickly from one standing-height grease point.</li><li>Service the lower bushing in the field using simple hand tools.</li>
<li>Lower bushing is rotatable – more service life lower parts cost.</li>
<li>Optional on-board autolube provides continual greasing as the hammer runs, protecting your investment.</li><li>Available for extreme environments, the optional wear package protects the hammer housing from damage.</li></ul>
<li>Auto shut off prevents blank firing, the leading cause of user-induced damage to hammers.</li><li>On a Next Gen Cat Excavator, hammers are protected by Auto-Stop, preventing damage from over-hammering in a single spot.</li><li>This feature helps prevent damage to your machine and premature damage to your hammer, even with inexperienced operators
<li>Performance Hammers lead in both operator comfort and machine protection.</li> The buffering system qualitatively dampens vibration to the machine due to proprietary buffering material.</li> <li>Can be configured for joystick or foot pedal control to suit your operating preference.</li></ul>
<li>Performance Hammers lead in both operator comfort and machine protection.</li> The buffering system qualitatively dampens vibration to the machine due to proprietary buffering material.</li> <li>Can be configured for joystick or foot pedal control to suit your operating preference.</li></ul>
<ul><li>All models include Product Link technology standard, you can locate the hammer via the Cat App on your phone.</li><li>When paired with a Next Gen Cat excavator, the hammer is automatically recognized and configured
<li>Cat hammer dimensions are included in Cat E-Fence technology – protects the cab, and keeps the hammer in safe areas on the job site.</li><li>Hammer pressure and flow controls can be monitored and configured via the in-cab monitor – manually or automatically.</li></ul>
<li>Cat hammer dimensions are included in Cat E-Fence technology – protects the cab, and keeps the hammer in safe areas on the job site.</li><li>Hammer pressure and flow controls can be monitored and configured via the in-cab monitor – manually or automatically.</li></ul>
